GFK-1504K Chapter 8 Discrete Output Modules 8-37
8
IC200MDL750
Output Module, 12/24VDC Positive Logic 0.5 Amp, 32 Points
Module Specifications
Module Characteristics
Points 2 groups of 16 outputs
Module ID 80808080
Isolation:
User input to logic (optical)
and to frame ground
Group to group
Point to point
250VAC continuous; 1500VAC for 1 minute
250VAC continuous; 1500VAC for 1 minute
None
LED indicators One LED per point shows individual point on/off state
FLD PWR LED indicates field power is present
OK LED indicates backplane power is present
Backplane current
consumption
5V output: 90mA maximum
External power supply +10.2 to +30VDC, +12/24VDC nominal
Thermal derating See diagrams
Output Characteristics
Output voltage +10.2 to +30VDC, +12/24VDC nominal
Output voltage drop 0.3V maximum
Load current 0.5A at 30VDC maximum (resistive)
2.0A maximum for 100ms inrush
Output leakage current 0.5mA at 30VDC maximum
On response time
Off response time
0.2ms, maximum
1.0ms maximum
Protection No internal fuses
