GFK-1504K Chapter 8 Discrete Output Modules 8-41
8
IC200MDL930
Output Module, Relay 2.0 Amp Isolated Form A 8 Points
Module Specifications
Module Characteristics
Points 8 individually isolated Form A relay outputs
Module ID FFFF8040
Isolation:
User input to logic (optical)
and to frame ground
Group to group
Point to point
250VAC continuous; 1500VAC for 1 minute
Not applicable
250VAC continuous; 1500VAC for 1 minute
LED indicators One LED per point shows individual point ON/OFF status
OK LED indicates backplane power is present
Backplane current
consumption
5V output: 245mA maximum. See graph
External power supply 0 to 125VDC, 5/24/125VDC nominal
0 to 265VAC (47 to 63Hz), 120/240VAC nominal
Thermal derating None
Output Characteristics
Output voltage 0 to 125VDC, 5/24/125VDC nominal
0 to 265VAC (47 to 63Hz), 120/240VAC nominal
Output voltage drop 0.3V maximum
Load current 10mA per point minimum
2.0A for 5 to 265VAC maximum (resistive)
2.0A for 5 to 30VDC maximum (resistive)
0.2A for 31 to 125VDC maximum (resistive)
Output leakage current Not applicable (open contact)
On response time
Off response time
10ms maximum
10ms maximum
Protection No internal fuses or snubbers
Switching frequency 20 cycles per minute (inductive load)
Relay type Fixed coil, moving armature
Contact type Silver alloy
Contact life See appendix B
