GFK-1504K Chapter 9 Discrete Mixed Modules 9-7
9
IC200MDD842
Mixed Module, Output 24VDC Pos. Logic 0.5A Grouped w/ESCP 16 Points
/ Input 24VDC Pos/Neg Logic Grouped 16 Points
Module Specifications
Module Characteristics
Points 1 group of 16 outputs
2 groups of 8 inputs
Module ID 80088080
Isolation:
User input to logic (optical)
and to frame ground
Group to group
Point to point
250VAC continuous; 1500VAC for 1 minute
250VAC continuous; 1500VAC for 1 minute
None
LED indicators One green LED per point shows individual point on/off state.
One amber LED per point shows individual point overloads for
outputs.
FLD PWR LED indicates field power is present
OK LED indicates backplane power is present
Backplane current consumption 5V output: 100mA maximum
External power supply +18 to +30VDC, +24VDC nominal
Thermal derating See diagram
Configuration parameters Input response time
Input Characteristics
Input voltage 0 to +30VDC, +24VDC nominal
On state voltage
Off state voltage
+15 to +30VDC
0 to +5VDC
On state current
Off state current
2.0 to 5.5mA
0 to 0.5mA
On response time
Off response time
0.5ms maximum
Additional configurable filter time 0 ms, 1.0ms (default), or 7.0ms
Input impedance 10kOhms maximum
Output Characteristics
Output voltage +18 to +30VDC, +24VDC nominal
Output voltage drop 0.5V maximum
Steady-state overcurrent trip point 1.6A typical, 0.7A to 2.5A maximum range
Load current 0.5 Amp at 30VDC maximum (resistive)
2.0 Amps maximum for 100ms inrush
Output leakage current 0.5mA at 30VDC maximum
On response time
Off response time
0.5ms maximum
0.5ms maximum
Protection (each output) Short circuit protection, overcurrent protection, free-wheeling
diodes
