IC200MDD843
Mixed Module, 24VDC Positive Logic Input Grouped 10 Points /
Output Relay 2.0A per Point Grouped 6 Points
Module Specifications
Module Characteristics
Points 10 Positive DC Inputs, one group,
6 Form A Relay Outputs, one group
Module ID FFFF8035
Isolation:
User input/output to logic
(optical) and frame ground
Group to group
Point to point
250VAC continuous; 1500VAC for 1 minute
250VAC continuous; 1500VAC for 1 minute
None
LED indicators One LED per point shows individual point on/off state
OK LED indicates backplane power is present
Backplane current consumption 5V output: 190mA maximum
External power supply 0 to 125VDC, 5/24/125VDC nominal
0 to 265VAC (47 to 63Hz), 120/240VAC nominal
Thermal derating None
Configuration parameters Input response time
Input Characteristics
Input voltage 0 to +30VDC, +24VDC nominal
On state voltage +15.0 to +30.0 VDC
Off state voltage 0 to +5.0 VDC
On state current
Off state current
2.0 to 5.5mA
0 to 0.5mA
On response time
Off response time
0.5ms maximum
Configurable filter time 0ms, 1.0ms (default), or 7.0ms
Input impedance 10kOhms maximum
Output Characteristics
Output voltage 0 to 125VDC, 5/24/125VDC nominal
0 to 265VAC (47 to 63Hz), 120/240VAC nominal
Output voltage drop 0.3V maximum
Load current 10mA per point minimum, 8.0A maximum per module
2.0 Amps for 5 to 265VAC maximum (resistive)
2.0 Amps for 5 to 30 VDC maximum (resistive)
0.2 Amp for 31 to 125 VDC maximum (resistive)
Output leakage current Not applicable (open contact)
On response time
Off response time
10ms maximum
10ms maximum
Protection No internal fuses or snubbers.
Switching frequency 20 cycles per minute (inductive load)
Relay type Fixed coil, moving armature
Contact type Silver alloy
Contact life See appendix B
