GFK-1504K Chapter 9 Discrete Mixed Modules 9-49
9
IC200MDD851
Mixed Module, Output 12/24VDC Positive Logic Grouped
16 Points / Input 5/12VDC Pos/Neg Logic Grouped 16 Points
Module Specifications
Module Characteristics
Points One group of 16 Outputs
Two groups of 8 Inputs
Module ID 80088080
Isolation:
User input/output to logic
(optical) and to frame ground
Group to group
Point to point
250VAC continuous; 1500VAC for 1 minute
250VAC continuous; 1500VAC for 1 minute
None
LED indicators One LED per point shows individual point on/off state
FLD PWR LED indicates field power is present
OK LED indicates backplane power is present
Backplane current consumption
5V output: 115mA maximum
External power supply
+10.2 to +30VDC, +12/24VDC nominal
Thermal derating See diagram
Configuration parameters Input response time
Input Characteristics
Input voltage 0 to +15VDC, +5/12VDC nominal
User input current 1.8mA typ. @ 5VDC, 4.9mA typ. @ 12VDC
Input impedance 2.4kOhms typ. @12VDC
On state voltage
Off state voltage
+4.2 to +15VDC
0 to +2.6VDC
On state current
Off state current
1.45mA minimum
0 to 0.7mA maximum
On response time
Off response time
0.25ms maximum
Configurable filter time 0ms, 1.0ms (default), or 7.0mS
Output Characteristics
Output voltage +10.2 to +30VDC, +12/24VDC nominal
Output voltage drop 0.3VDC maximum
Load current 0.5 Amp at 30VDC maximum (resistive)
2.0 Amps maximum for 100ms inrush
Output leakage current 0.5mA at 30VDC maximum
On response time
Off response time
0.2ms maximum
1.0ms maximum
Protection No internal fuses
