GFK-1504K Chapter 13 Mixed Discrete/High-speed Counter Module 13-3
13
IC200MDD841
Mixed Module, 24VDC Positive Logic Input 20 Points / Output 12 Point /
(4) High Speed Counter, PWM, or Pulse Train Configurable Points
LED
Indicators
Individual green field-side LEDs show the on/off status of each point
The green FLD PWR LED indicates the presence of field power for the DC outputs.
The OK LED indicates module status.
On green indicates normal operation.
Flashing green indicates boot mode or update
On Amber indicates self diagnostic error
Off indicates no 3.3V power present.
Configuration Parameters
The module has many features that are selectable by software configuration. These
features include:
Counter type
Output stop mode
Channel function
Counter output enable
Counter direction
Counter mode
Counter Preload/Strobe selection
Type A counter count input edge
Counter timebase
High and low limits
On and off Presets
Preload registers
Pulse-train acceleration
Pulse-train deceleration
