A-8 VersaMax® Modules, Power Supplies, and Carriers User's Manual – March 2003 GFK-1504K

Terminal-Style I/O Carrier to Terminal-Style I/O Carrier and Auxiliary Terminals to Terminal-

Style I/O Carrier

.000

.689in REF

17.5mm

1.819in

46.2mm

4.010in

101.9mm

IC200CHS002

4.350in

110.5mm

8.360in

212.3mm

IC200TBM002

4.350in

110.5mm

IC200CHS002

.000

Terminal-Style Carrier to Connector-Style Carrier (shown), Compact Terminal-Style I/O

Carrier, or Power Supply Booster Carrier

.000

.689in REF

17.5mm

1.819in

46.2mm

IC200CHS002

.000

4.010in

101.9mm

4.350in

110.5mm
