GFK-1504K Appendix A Panel Mounting Dimensions A-9

Connector-Style I/O Carrier to Connector-Style I/O Carrier (shown), Compact Terminal-Style

I/O Carrier, Communications Carrier, or Power Supply Booster Carrier

.000

.689in REF

17.5mm

1.819in

46.2mm

.000

2.630in

66.8mm
