A-10 VersaMax® Modules, Power Supplies, and Carriers User's Manual – March 2003 GFK-1504K

Interposing Terminals to Interposing Terminals

.000

.689in REF

17.5mm

1.819in

46.2mm

IC200CHS012

.000 4.010in

101.9mm

4.350in

110.5mm

8.360in

212.3mm

IC200CHS012

Connector-Style I/O Carrier (shown) or Compact Terminal-Style I/O Carrier to Terminal-Style

I/O Carrier

.000

.689in REF

17.5mm

1.819in

46.2mm

.000

2.630in

66.8mm

IC200CHS002

6.640in

168.7mm
