C-4 VersaMax® Modules, Power Supplies, and Carriers User's Manual – March 2003 GFK-1504K
C
Catalog
Number
Description
Backplane Current
Consumption in mA
5V 3.3V
IC200ALG320
Analog Output Module, 12 Bit Current, 4 Channels
50
IC200ALG321
Analog Output Module, 12 Bit Voltage 0 to 10VDC 4 Channels
50
IC200ALG322
Analog Output Module, 12 Bit Voltage -10 to +10VDC 4 Channels
50
IC200ALG325
Analog Output Module, 13 Bit Voltage 8 Channels
50
IC200ALG326
Analog Output Module, 13 Bit Current 8 Channels
50
IC200ALG327 Analog Output Module, 13 Bit Voltage 12 Channels 50
IC200ALG328 Analog Output Module, 13 Bit Current 12 Channels 50
IC200ALG331 Analog Output Module, 16 Bit Voltage/Current, 1500VAC
Isolation, 4 Channels
10 115
IC200ALG430 Analog Mixed Module, 12 Bit Input Current 4 Channels and
Output Current 2 Channels
50
IC200ALG431 Analog Mixed Module, 12 Bit 0 to 10VDC Input 4 Channels and
Output 2 Channels
60
IC200ALG432 Analog Mixed Module, 12 Bit +/-10VDC Input 4 Channels and
Output 2 Channels
60
IC200ALG620 Analog Input Module, 16 Bit RTD, 4 Channels 125 125
IC200ALG630 Analog Input Module, 16 Bit Thermocouple, 7 Channels 125 125
IC200MDD840 Mixed Module, 24VDC Positive Logic Input 20 Points / Output
Relay 2.0 Amp 12 Points
375
IC200MDD841 Mixed Module, 24VDC Positive Logic Input 20 Points / Output 12
Point / (4) High Speed Counter, PWM, or Pulse Train
Configurable Points
30 130
IC200MDD842
Mixed Module, Output 24VDC Pos. Logic 0.5A Grouped w/ESCP
16 Points / Input 24VDC Pos/Neg Logic Grouped 16 Points
100
IC200MDD843 Mixed Module, 24VDC Positive Logic Input Grouped 10 Points /
Output Relay 2.0A per Point Grouped 6 Points
190
IC200MDD844
Mixed Module, Output 12/24VDC Pos. Logic 0.5A 16 Points /
Input 24 VDC Pos/Neg Logic Grouped 16 Points
70
IC200MDD845
Mixed Module, Output Relay 2.0A Isolated 8 Points / Input
24VDC Pos/Neg Logic Grouped 16 Points
270
IC200MDD846 Mixed Module, Output Relay 2.0A per Pt Isolated 8 Points / Input
120VAC Grouped 8 Points
300
IC200MDD847 Mixed Module, Output Relay 2.0A per Pt Isolated 8 Points / Input
240VAC Grouped 8 Points
300
IC200MDD848 Mixed Module, Output 120VAC 0.5A per Pt Isolated 8 Points /
Input 120VAC Grouped 8 Points
125
IC200MDD849 Mixed Module, Output Relay 2.0A per Pt Isolated 8 Points / Input
120VAC Isolated 8 Points
295
IC200MDD850 Mixed Module, Output Relay 2.0A per Pt Isolated 8 Points / Input
240VAC Isolated 4 Points
275
IC200MDD851 Mixed Module, Output 12/24VDC Pos. Grouped 16 Pts / Input
5/12VDC Pos/Neg Grp16 Pts
115
