GFK-1504K Appendix C Power Supply Load Requirements C-5
C
Catalog
Number
Description
Backplane Current
Consumption in mA
5V 3.3V
IC200MDL140 Input Module, 120VAC 8 Points 55
IC200MDL141 Input Module, 240VAC 8 Points 55
IC200MDL143 Input Module, 120VAC Isolated 8 Points 50
IC200MDL144 Input Module, 240VAC Isolated 4 Points 30
IC200MDL240 Input Module, 120VAC 16 Points 110
IC200MDL241 Input Module, 240VAC16 Points 110
IC200MDL243 Input Module, 120VAC Isolated 16 Points 100
IC200MDL244 Input Module, 240VAC Isolated 8 Points 60
IC200MDL329 Output Module, 120VAC 0.5 Amp, Isolated 8 Points 70
IC200MDL330 Output Module, 120VAC 0.5 Amp, Isolated 16 Points 140
IC200MDL331 Output Module, 120VAC 2.0 Amp, Isolated 8 Points 85
IC200MDL631 Input Module, 125VDC Positive/Negative Logic Isolated 8 Points 40
IC200MDL632 Input Module, 125VDC Positive/Negative Logic Isolated 16
Points
80
IC200MDL635 Input Module, 48VDC Positive/Negative Logic Grouped 16 Points 70
IC200MDL636 Input Module, 48VDC Positive/Negative Logic Grouped 32 Points 140
IC200MDL640 Input Module, 24VDC Positive/Negative Logic 16 Points 25
IC200MDL643 Input Module, 5/12VDC Positive/Negative Logic Grouped 16
Points
70
IC200MDL644 Input Module, 5/12VDC Positive/Negative Logic Grouped 32
Point
140
IC200MDL650 Input Module, 24VDC Positive/Negative Logic 32 Points 50
IC200MDL730 Output Module, 24VDC Positive Logic 2.0 Amps, w/ESCP 8
Points
50
IC200MDL740 Output Module, 12/24VDC Positive Logic 0.5 Amp, 16 Points 45
IC200MDL741 Output Module, 24VDC Positive Logic 0.5 Amp, w/ESCP 16
Points
75
IC200MDL742 Output Module, 24VDC Positive Logic 0.5 Amp, w/ESCP 32
Points
150
IC200MDL743 Output Module, 5/12/24V DC Negative Logic 0.5 Amp, 16 Points 70
IC200MDL744 Output Module, 5/12/24VDC Negative Logic 0.5 Amp, 32 Points 140
IC200MDL750 Output Module, 12/24VDC Positive Logic 0.5 Amp, 32 Points 90
IC200MDL930 Output Module, Relay 2.0 Ampt Isolated Form A 8 Points 245
IC200MDL940 Output Module, Relay 2.0 Amp, Isolated Form A 16 Points 490
