GFK-1504K Chapter 4 Carriers 4-13

IC200CHS005

Spring-Style I/O Carrier

Field Wiring Terminals

Each terminal accommodates one solid or stranded AWG #14 (avg. 2.1mm

cross section)

to AWG #22 (avg. 0.36mm

cross section) wire, or two wires up to AWG #18 (avg.

0.86mm

cross section).

A1 A2 A3

A5 A6 A7 A8 A9 A11 A12 A13

A14

A15 A16 A17 A18

A10

B2 B3

B5 B6 B7 B8 B9 B11 B12 B13 B14 B15 B16 B17 B18

B10

The carrier accommodates current levels up to 2 Amps per point or 8 Amps per each

power and ground, and a voltage range of up to 264 VAC. Voltage transients up to 300

VAC will not damage the carrier.

One or more Auxiliary I/O Terminal Strips can be added to provide extra field wiring

connections if needed. Auxiliary I/O Terminal Strips insert directly into the lower edge of

the I/O Carrier.
