4-14 VersaMax® Modules, Power Supplies, and Carriers User's Manual – March 2003 GFK-1504K

IC200CHS022

Compact Box-Style I/O Carrier

The Compact Box-Style I/O Carrier (IC200CHS022) has 36 IEC box-style terminals. It

provides mounting, backplane communications, and field wiring for one I/O module.

66.8mm

(2.63in)

163.5mm

(6.45in)

IND CONT EQ FOR HAZ LOC

CLASS I DIV 2 GROUPS ABCD

Temp Code T4 Ambient 60C

CLASS 1 ZONE 2 GROUP IIC

Ex nA IIC 0C <To<60C

Ex nV II Demko No. 98Y.125014

IC200CHS022

COMPACT I/O CARRIER

BOX STYLE

The I/O module mounts vertically (perpendicular to the DIN rail) on this carrier.
