184
Standard:
Result and solution:
Normal Replace the combination meter assembly
If abnormal inspect the water temperature sensor
2 Inspect the water temperature sensor
 Remove the water temperature sensor and put it into the constant temperature cabinet.
 Adjust the temperature in the constant temperature cabinet and measure the resistance of the
water temperature sensor.
Standard:
Result and solution:
Normal Repair or replace the harness and connector
If abnormal replace the water temperature sensor
Tester connection Condition Standard condition
C(60
℃
)164.5±5Ω
1/2C(90
℃
) 56±3Ω
H(115
℃
)28.7±2Ω
B5 - ground
Condition Standard condition
C(60
℃
) 164.5±5Ω
1/2C(90
℃
)56±3Ω
H(115
℃
) 28.7±2Ω
