II. MALFUNCTION INSPECTION
1. WASHER PUMP INSPECTION
(1) Mount washer pump on the can system. Pour washer fluid into the can.
(2) Disconnect the connector of washer pump.
(3) Connect the terminal 1 of washer pump to the battery positive (+) and the terminal 2 to the negative (-),
as shown below. Inspect that the washer fluid flows out of the can.
(4) If not, replace the washer pump.
2. WIPER SWITCH ASSEMBLY
(a) Inspect the continuity
 Inspect each terminal on connector for continuity.
Standard:
Switch position Tested terminal Specified condition
MIST 8
（
+
）
—10
（
+
）
Continuity
OFF 3
（
+
）
—10
（
+
）
Continuity
INT 8
（
+
）
—6
（
+
）
3
（
+
）
—10
（
+
）
Continuity
LO 8
（
+
）
—10
（
+
）
Continuity
HI 8
（
+
）
—11
（
-
）
Continuity
