1.Front Door Removal/Installation
(1) Disconnect the negative (--) terminal cable from the battery.
(2) Remove the front fender and remove the front door hinge.
(3) Remove the connector (See Notice on Removing the
Connector for detailed information)
(4) Remove front door hinges
(5) Remove the front door
(6) The installation is in the reverse order of the removal.
(7) Adjust the front door. (See Door Adjustment for detailed
information)
Front Door inner trim
1. Front Door Inner Trim Board Assembly 2.Front Door Inner Handle Assembly 3.Trim Board
4.Door Handle 5.Set Screw
1
2
4
3
5
2
