Set Screw
352
1.The Front Door Inner Trim Board Removal/Installation
(1) Remove the set screw.
(2) Remove the front door inner trim board assembly.
(3) Disassemble the inner trim board assembly as required
(4) The installation is in the reverse order of the removal.
2.Front Door Glass Removal And Installation
(1) Lift the front door window glass, make the distance between
the front window glass top and rear door top weatherstrip
to be 130mm.
(2) Disconnect the negative (--) terminal cable from the battery.
(3) Remove the front door frame.
(4) Remove the hole cover.
(5) Remove the screw.
(6) Insert your hand into the front door component hole to lift
the front window glass.
(7) The installation is in the reverse order of the removal.
3.Glass Regulator Removal/Installation
(1) Loose the set screw: (See Figure)
Front
Door
Glass
To Next Page
