Code Parameter Name / Range
13-12 PG Card Id
0~255
This parameter displays the ID of option card on the control board. It is only displayed coupled with the option
card.
(0): none
(1): EXP-LD-VDI100
(2): EXP-OC-VDI100
(3): EXP-LD-PM-VDI100
(4): EXP-SC-PM-VDI100
(5): EXP-RS-PM-VDI100
(6): -
(7): -
(8): -
Code Parameter Name / Range
13-13 PG Card Ver.
0.00~9.99
This parameter displays the CPLD software version of the option card on the control board. It is only displayed
coupled with the option card.
Code Parameter Name / Range
13-14 Fault Storage Selections
0: Fault Messages of Auto Restart are not saved.
1: Fault Messages of Auto Restart are saved.
13-14=0, the fault messages are not saved in the fault history (12-46~12-49) in the process of restart when the
auto reset function is active.
13-14=1, the fault messages are saved in the fault history (12-46~12-49) in the process of restart when the
auto reset function is active.
Code Parameter Name / Range
13-15
Reserved
Code Parameter Name / Range
13-21~13-50
Note: 13-21~13-50 are 30 Fault History: When it detect fault, inverter will store to fault history. If it happen fault again, 13-
21 will change to 13-22.
VDI100 • Instruction manual 245
