Steps Keypad (English) Description
3
Edit 16-07
Copy Sel
Normal
(0 – 3)
< 0 >
0
Press the Read / Enter key to display the data setting / read screen (LCD display is
inversed).
4
Edit 16-07
Copy Sel
VERIFY
(0 – 3)
< 0 >
3
Change the set value to 3 (verify) by using the up arrow key.
5
-ADV-
VERIFY
INV → OP
• Use Read / Enter key to enable the read operation, the display is shown as the left.
• The bottom of LCD display will show a bar to indicate the read progress.
6
-ADV-
VERIFY
COMPLETE
“VERIFY COMPLETE” will be displayed on the keypad when writing was successful.
VRYE
Verify Error
• The error message of “VRYE Verify Error " may occur on the keypad when writing
parameters to the inverter is prohibited.
• If the error is displayed, press any key to remove the error message and go back to
parameter 16-07.
7
Edit 16-07
Copy Sel
VERIFY
(0 – 3)
< 0 >
3
When DSP/FUN key is pressed, the display returns to parameter 16-07.
Code Parameter Name / Range
16-09 Selection of keypad removed (LCD)
0: Keep operating when LCD keypad is removed.
1: Display fault when LCD keypad is removed.
16-09=0: Continue operating when keypad is removed.
16-09=1: Trip inverter when keypad is removed while operating in local mode.
252 VDI100 • Instruction manual
