gefran VDI100 Series User Manual

■ WRITE:CopyKeypadparameterstotheInverter
Steps Keypad (English) Description
1
Group
14 PLC Setting
15 PLC Monitor
16 LCD Keypad Func.
Select the copy function group (16) from the group menu.
2
PARA 16
-08：READ Sel
-09：Keypad Loss Sel
-07：Copy Sel
Press the Read / Enter key and select parameter (16-07) copy sel.
3
Edit 16-07
Copy Sel
Normal
(0 – 3)
< 0 >
0
Press the Read / Enter key to display the data setting / read screen (LCD display is
inversed).
4
Edit 16-07
Copy Sel
WRITE
(0 – 3)
< 0 >
2
Change the set value to 2 (write) by using the up arrow key.
5
-ADV-
WRITE
INV → OP
• Use Read / Enter key to enable the read operation, the display is shown as the left.
• The bottom of LCD display will show a bar to indicate the read progress.
6
-ADV-
WRITE
COMPLETE
“WRITE COMPLETE” will be displayed on the keypad when writing was successful.
WRE
Write Error
• The error message of “WRE Write Error " may occur on the keypad when writing
parameters to the inverter is prohibited.
• If the error is displayed, press any key to remove the error message and go back to
parameter 16-07.
7
Edit 16-07
Copy Sel
WRITE
(0 – 3)
< 0 >
2
When DSP/FUN key is pressed, the display returns to parameter 16-07.
■Verify:CompareInverterParametersagainstKeypadParameters
Steps Keypad (English) Description
1
Group
14 PLC Setting
15 PLC Monitor
16 LCD Keypad Func.
Select the copy function group (16) from the group menu.
2
PARA 16
-08：READ Sel
-09：Keypad Loss Sel
-07：Copy Sel
Press the Read / Enter key and select parameter (16-07) copy sel.
VDI100 • Instruction manual 251
