Never connect or disconnect the motor from the inverter while the inverter is outputting voltage.
Improper equipment sequencing could result in damage to the inverter.
Do not use unshielded cable for control wiring.
Failure to comply may cause electrical interference resulting in poor system performance. Use shielded twist-
ed-pair wires and ground the shield to the ground terminal of the inverter.
Do not modify the inverter circuitry.
Failure to comply could result in damage to the inverter and will void warranty.
Gefran is not responsible for any
modication of the product made by the user. This product must not be modied.
Check all the wiring to ensure that all connections are correct after installing the inverter and connect-
ing any other devices.
Failure to comply could result in damage to the inverter.
Ne jamais brancher/débrancher le moteur sur/de l’inverseur alors que celui-ci est en train de débiter de
la tension.
Unséquençageinadaptédel’équipementpeutendommagerl’inverseur.
Ne pas utiliser un câble non blindé pour le câblage de commande.
Lenon-respectdecetteprescriptionpeutprovoquerdesinterférencesélectriques,responsablesàleurtourde
dysfonctionnementsdusystème.Utiliserdespairestorsadéesblindéesetbrancherleblindagesurleterminale
deterredel’inverseur.
Ne pas modier les circuits de l’inverseur.
Lenon-respectdecetteprescriptionpeutendommagerl’inverseuretannulersagarantie.Gefrannesaurait
êtretenuepourresponsabledesmodicationsapportéesauproduitparleclient.Ceproduitnedoitpasêtre
modié.
Après avoir installé l’inverseur et avoir branché d’autres dispositifs, vérier tous les câblages pour
s’assurer que les branchements sont corrects.
Lenon-respectdecetteprescriptionpeutendommagerl’inverseur.
■ UL Standards
The UL/cUL mark applies to products in the United States and Canada and it means that UL has performed
product testing and evaluation and determined that their stringent standards for product safety have been met.
For a product to receive UL certication, all components inside that product must also receive UL certication.
■ UL Standards Compliance
This inverter is tested in accordance with UL standard UL508C and complies with UL requirements. To ensure
continued compliance when using this inverter in combination with other equipment, meet the following condi-
tions:
■ Installation Area
Do not install the inverter to an area greater than pollution severity 2 (UL standard).
■ Main Circuit Terminal Wiring
UL approval requires crimp terminals when wiring the inverter’s main circuit terminals. Use crimping tools as
specied by the crimp terminal manufacturer.
Gefran recommends crimp terminals made by “Nichifu” for the
insulation cap.
The table below matches inverter models with crimp terminals and insulation caps. Orders can be placed with a
Gefran representative or directly with the Gefran sales department.
Caution
VDI100 • Instruction manual 355
