Closed-LoopCrimpTerminalSize
VDI100
Wire gauge (AWG) Terminal Crimp Terminal Tool Insulation Cap
R/L1 S/L2 T/L3 U/T1, V/T2,W/T3 Screws Model No. Machine No. Model No.
230V class three-phase drives
1007-1015
2.5 (14)
M4
R2-4
Nichifu NH 1/9
TIC 2
4.0 (12)
R5.5-4
TIC 3.5
6.0 (10) TIC 5.5
2022
6.0 (10) M4 R5.5-4 Nichifu NH 1/9 TIC 5.5
2037
2055
3075 10.0 (8) M4 R8-4 Nichifu NOP 60 TIC 8
4110
25 (4) M6 R22-6 Nichifu NOP 60/150H TIC 224150
4185
5220 55 (1/0) M8 R60-8 Nichifu NOP 60/150H TIC 60
400V class three-phase drives
1007-1015-1022
2.5 (14)
M4
R2-4
Nichifu NH 1/9
TIC 2
4.0 (12)
R5.5-4
TIC 3.5
6.0 (10) TIC 5.5
2037-2055
4.0 (12)
M4 R5.5-4 Nichifu NH 1/9
TIC 3.5
6.0 (10) TIC 5.5
3075
10.0 (8) M4 R8-4 Nichifu NOP 60 TIC 83110
3150 - 4150
4185
16 (6) M6 R14-6 Nichifu NOP 60/150H TIC 14
4220
5300
35 (2) M8 R38-8 Nichifu NOP 60/150H TIC 38
5370
5450
5550
6750
95 (3/0) M10 R80-10 Nichifu NOP 150H TIC 80
6900
71100
120 (4/0)*2 M10 R100-10 Nichifu NOP 150H TIC 10071320
71600
- Type 1
During installation, all conduit hole plugs shall be removed, and all conduit holes shall be used.
VDI100
Fuse Type
Manufacturer: Bussmann/ FERRAZ SHAWMUT
Model Fuse ampere rating(A)
200V class three-phase drives
1007 Bussmann 20CT 690 V / 20 A
1015 Bussmann 30FE 690 V / 30 A
2022 Bussmann 50FE 690 V / 50 A
2037 Bussmann 50FE 690 V / 50 A
2055 Bussmann 63FE 690 V / 63 A
3075 FERRAZ SHAWMUT A50QS100-4 500 V / 100 A
4110 Bussmann 120FEE / FERRAZ A50QS150-4 690 V / 120 A - 500 V / 150 A
4150 FERRAZ SHAWMUT A50QS150-4 500 V / 150 A
4185 FERRAZ SHAWMUT A50QS200-4 500 V / 200 A
5220 FERRAZ SHAWMUT A50QS250-4 500 V / 250 A
356 VDI100 • Instruction manual
