gefran VDI100 Series User Manual

VDI100
Fuse Type
Manufacturer: Bussmann/ FERRAZ SHAWMUT
Model Fuse ampere rating(A)
400V class three-phase drives
1007 Bussmann 10CT 690 V / 10 A
1015 Bussmann 16CT 690 V / 16 A
1022 Bussmann 16CT 690 V / 16 A
2037 Bussmann 25ET 690 V / 25 A
2055 Bussmann 40FE 690 V / 40 A
3075 Bussmann 50FE 690 V / 50 A
3110 Bussmann 63FE 690 V / 63 A
4150 Bussmann 80FE 690 V / 80 A
4185 Bussmann 100FE / FERRAZ A50QS100-4 690 V / 100 A - 500 V / 100A
4220 Bussmann 120FEE 690 V / 120 A
5300 FERRAZ SHAWMUT A50QS150-4 690 V / 150 A
5370 FERRAZ SHAWMUT A50QS200-4 690 V / 200 A
5450 FERRAZ SHAWMUT A50QS250-4 690 V / 250 A
5550 FERRAZ SHAWMUT A50QS300-4 690 V / 300 A
6750 FERRAZ SHAWMUT A50QS400-4 690 V / 400 A
6900 FERRAZ SHAWMUT A50QS500-4 690 V / 500 A
71100 FERRAZ SHAWMUT A50QS600-4 690 V / 600 A
71320 FERRAZ SHAWMUT A50QS700-4 690 V / 700 A
71600 FERRAZ SHAWMUT A50QS700-4 690 V / 700 A
- Motor Overtemperature Protection
Motor overtemperature protection shall be provided in the end use application.
■ FieldWiringTerminals
All input and output eld wiring terminals not located within the motor circuit shall be marked to indicate the
proper connections that are to be made to each terminal and indicate that copper conductors, rated 75°C are to
be used.
■ InverterShort-CircuitRating
This inverter has undergone the UL short-circuit test, which certies that during a short circuit in the power sup-
ply the current ow will not rise above value. Please see electrical ratings for maximum voltage and table below
for current.
• The MCCB and breaker protection and fuse ratings (refer to the preceding table) shall be equal to or greater
than the short-circuit tolerance of the power supply being used.
• Suitable for use on a circuit capable of delivering not more than ( A ) RMS symmetrical amperes for ( Hp ) in
240 / 480 V class drives motor overload protection:
Power
(kW)
Horse Power
(HP)
Current (A) Voltage (V)
0.75 - 37 1 - 50 5,000 240 / 480
38 - 149 51 - 200 10,000 240 / 480
150 - 298 201 - 400 18,000 240 / 480
299 - 447 401 - 600 30,000 240 / 480
VDI100 • Instruction manual 357
