Group 00: Basic Parameters
Code Parameter Name Setting Range Default Unit
Control mode
Attribute
V/f
V/f
+PG
SLV SV
PM
SV
PM
SLV
SLV2
00-00 Control Mode Selection
0: V/f
0 - O O O O O O O *3
1: V/f+PG
2: SLV
3: SV
4: PMSV
5: PMSLV
6: SLV2
00-01 Motor’s Rotation Direction
0: Forward
0 - O O O O O O O *1
1: Reverse
00-02
Main Run Command Source
Selection
0: Keypad
1 - O O O O O O O
1: External Terminal (Control Circuit)
2: Communication Control (RS-485)
3: PLC
00-03
Alternative Run Command
Selection
0: Keypad
2 - O O O O O O O
1: External Terminal (Control Circuit)
2: Communication Control (RS-485)
3: PLC
00-04 Language
0: English
0 - O O O O O O O
1: Simplified Chinese
2: Traditional Chinese
3: Turkish
00-05
Main Frequency Command
Source Selection
0: Keypad
1 - O O O O O O O
1: External Terminal (Analog 1)
2: Terminal Command UP/DOWN
3: Communication Control (RS-485)
4: Pulse Input
5: Reserved
6: Reserved
7: AI2 Auxiliary Frequency
00-06
Alternative Frequency
Source Selection
0: Keypad
3 - O O O O O O O
1: External Terminal (Analog 1)
2: Terminal Command UP/DOWN
3: Communication Control (RS-485)
4: Pulse Input
5: Reserved
6: Reserved
7: AI2 Auxiliary Frequency
00-07
Main and Alternative Fre-
quency Command Modes
0: Main Frequency
0 - O O O O O O O
1: Main frequency + Alternative Fre-
quency
00-08
Communication Frequency
Command Range
0.00~599.00 0.00 Hz O O O O O O O
00-09
Communication Frequen-
cy Command Memory
Selection
0: Don’t save when power supply is off.
(00-08)
0 - O O O O O -
1: Save when power is off. (00-08)
00-10
Minimum frequency
detection
0:Show warning if lower than minimum
frequency
0 - O O O O O O O
1:Run as minimum frequency if lower
than minimum frequency
00-11
PID Lower Limit of Frequen-
cy Selection
0: PID Sleep Limit is Lower Limit of
Frequency
0 - O O O O O O O
1: PID Sleep Limit is 0Hz
00-12 Upper Frequency limit 0.1~109.0 100.0 % O O O O O O O
00-13 Lower Frequency limit 0.0~109.0 0.0 % O O O O O O O
00-14 Acceleration Time 1 0.1~6000.0 * s O O O O O O O *1
00-15 Deceleration Time 1 0.1~6000.0 * s O O O O O O O *1
00-16 Acceleration Time 2 0.1~6000.0 * s O O O O O O O *1
00-17 Deceleration Time 2 0.1~6000.0 * s O O O O O O O *1
00-18 *Jog Frequency 0.00~599.00 6.00 Hz O O O O O O O *1
00-19 Jog Acceleration Time 0.1~0600.0 - s O O O O O O O *1
00-20 Jog Deceleration Time 0.1~0600.0 - s O O O O O O O *1
VDI100 • Instruction manual 57
