Group 00: Basic Parameters

Code Parameter Name Setting Range Default Unit

Control mode

Attribute

V/f

+PG

SLV SV

SLV

SLV2

00-21 Acceleration time 3 0.1~6000.0 * s O O O O O O O *1

00-22 Deceleration time 3 0.1~6000.0 * s O O O O O O O *1

00-23 Acceleration time 4 0.1~6000.0 * s O O O O O O O *1

00-24 Deceleration time 4 0.1~6000.0 * s O O O O O O O *1

00-25

Switch-Over Frequency of

Acc/Dec Time 1 and Time 4

0.00~599.00 0.0 Hz O O O O O O O

00-26 Emergency Stop Time 0.1~6000.0 5.0 s O O O O O O O

00-27 HD/ND Mode Selection ***

0: HD (Heavy Duty Mode)

0 - O O X X X X X *3

1: ND (Normal Duty Mode)

00-28

Command Characteris-

tic selection of master

frequency

0: Positive Characteristic (0~10V/4~-

20mA is corresponding to 0~100%)

0 - O O O O O O O

1: Negative Characteristic (0~10V/4~-

20mA is corresponding to 100~0%)

00-29

Zero-Speed Operation

Selection

0: Operation Based on Frequency Com-

mand

0 - X X X O O X X

1: Stop

2: Operation Based on the Lowest

Frequency

3: Zero-Speed Operation

00-30 Reserved

00-31 Reserved

00-32

Application Selection

Presets**

0: General

0 - O O O O O O O

Reserved

2: Conveyor

3: Exhaust Fan

Reserved

5: Compressor

6: Hoist**

7: Crane**

00-33

Modified Parameters (only

for LCD keypad)

0:Disable

0 - O O O O O O O *7

1:Enable

00-34

00-40

Reserved

00-41 User parameter 0

Set 13-06 = 1, start user parameter. The

setting range is 01-00 ~24-06 (only for

LCD keypad)

00-41 - O O O O O O O *7

00-42 User parameter 1 00-42 - O O O O O O O *7

00-43 User parameter 2 00-43 - O O O O O O O *7

00-44 User parameter 3 00-44 - O O O O O O O *7

00-45 User parameter 4 00-45 - O O O O O O O *7

00-46 User parameter 5 00-46 - O O O O O O O *7

00-47 User parameter 6 00-47 - O O O O O O O *7

00-48 User parameter 7 00-48 - O O O O O O O *7

00-49 User parameter 8

Set 13-06 = 1, start user parameter. The

setting range is 01-00 ~24-06. (only for

LCD keypad)

00-49 - O O O O O O O *7

00-50 User parameter 9 00-50 - O O O O O O O *7

00-51 User parameter 10 00-51 - O O O O O O O *7

00-52 User parameter 11 00-52 - O O O O O O O *7

00-53 User parameter 12 00-53 - O O O O O O O *7

00-54 User parameter13 00-54 - O O O O O O O *7

00-55 User parameter 14 00-55 - O O O O O O O *7

00-56 User parameter 15 00-56 - O O O O O O O *7

00-57 SV High Speed Mode

0: SV High Speed Mode1

0 - X X X O

X X X

1: SV High Speed Mode2

*: Refer to the following attachment 1.

**: Before to set up 00-32 Application, it should do initialized setting (parameter 13-08) first. When setting 00-32, the I/O port function changed automatically. To avoid accident,

be sure to confirm the I/O port signal of inverter and external terminal control.

*** If parameter 00-27 is set to ND mode, group 02 motor 1 parameter will automatically adjust to more than 1 class of it.

If parameter 00-27 is set to HD mode, group 02 motor 1 parameter will automatically adjust to the same class of it.

It is suggested that parameter 00-27 be set first before motor performs auto-tuning because the parameter will make the motor parameter automatically be changed.

***** If the maximum output frequency of motor is over 300HZ,the frequency resolution is changed to 0.1Hz

58 VDI100 • Instruction manual
