Group 01: V/f Control Parameters
Code Parameter Name Setting Range Default Unit
Control mode
Attribute
V/f
V/f
+PG
SLV SV
PM
SV
PM
SLV
SLV2
01-00 V/f Curve Selection 0~FF F - O O X X X X O *3
01-01 Reserved
01-02
Maximum Output Frequen-
cy of Motor 1
5.0~599.0 60.0 Hz O O O O O O O
01-03
Maximum Output Voltage of
Motor 1
230V: 0.1~255.0
220.0 V O O X X X X O
400V: 0.2~510.0
01-04
Middle Output Frequency 2
of Motor 1
0.0~599.0 0.0 Hz O O X X X X O
01-05
Middle Output Voltage 2 of
Motor 1
230V: 0.0~255.0
0.0 V O O X X X X O
400V: 0.0~510.0
01-06
Middle Output Frequency 1
of Motor 1
0.0~599.0 3.0 Hz O O X X X X O
01-07
Middle Output Voltage 1 of
Motor 1
230V: 0.0~255.0
* V O O X X X X O
400V: 0.0~510.0
01-08
Minimum Output Frequency
of Motor 1
0.0~599.0
VF:1.5
Hz O O O O O O O
VF+PG:
1.5
SLV: 0.6
SV:0.1
PM SV:0.1
PM
SLV:9.0
SLV2:
1.0
01-09
Minimum Output Voltage of
Motor 1 (for
2.2~22kW)
230V: 0.0~255.0
7.5 V O O X X X X O
400V: 0.0~510.0
01-10 Torque Compensation Gain 0.0~2.0 0.5 - O O X X X X O *1
01-11
Selection of Torque Com-
pensation Mode
0: Torque Compensation Mode 0
0 - O O X X X X X
1: Torque Compensation Mode 1
01-12 Base Frequency of Motor 1 5.0~599.0 60.0 Hz O O O O O O O
01-13
Base Output Voltage of
Motor 1
230V: 0.0~255.0 220.0 V O O X X X X O
400V: 0.0~510.0 440.0
01-14 Input Voltage Setting
230V: 155.0~255.0 220.0
V O O O O O O O
400V: 310.0~510.0 440.0
01-15 Torque Compensation Time 1~10000 200 ms O O X X X X O
01-16
Maximum Output Frequen-
cy of Motor 2
5.0~599.0 60.0 Hz O X X X X X X
01-17
Maximum Output Voltage of
Motor 2
200V: 0.1~255.0 220.0
V O X X X X X X
400V: 0.2~510.0 440.0
01-18
Middle Output Frequency 2
of Motor 2
0.0~599.0 0.0 Hz O X X X X X X
01-19
Middle Output Voltage 2 of
Motor 2
230V: 0.0~255.0
0.0 V O X X X X X X
400V: 0.0~510.0
01-20
Middle Output Frequency 1
of Motor 2
0.0~599.0 3.0 Hz O X X X X X X
01-21
Middle Output Voltage 1 of
Motor 2 (
for 2.2~22kW)
230V: 0.0~255.0 14.0
V O X X X X X X
400V: 0.0~510.0 28.0
01-22
Minimum Output Frequency
of Motor 2
0.0~599.0 1.5 Hz O X X X X X X
01-23
Minimum Output Voltage of
Motor 2 (for
for 2.2~22kW)
230V: 0.0~255.0 7.5
V O X X X X X X
400V: 0.0~510.0 15.0
01-24 Base Frequency of Motor 2 5.0~599.0 60.0 Hz O X X X X X X
01-25
Base Output Voltage of
Motor 2
230V: 0.0~255.0 220.0
V O X X X X X X
400V: 0.0~510.0 440.0
01-26
V/f Curve Selection of
Motor 2
0~FF F - O X X X X X X *3
*: Refer to the attachment 1.
VDI100 • Instruction manual 59
