gefran VDI100 Series User Manual

Group 02: IM Motor Parameters
Code Parameter Name Setting Range Default Unit
Control mode
Attribute
V/f
V/f
+PG
SLV SV
PM
SV
PM
SLV
SLV2
02-00
Control mode selection 0.01~600.00 - A O X X X X X O
02-01 Rated Current of Motor1
Modes of V/f, V/f+PG are 10%~200% of
inverter’s rated current. Modes of SLV,
SV are 25%~200% of inverter’s rated
current.
- A O O O O X X O
02-02 Reserved
02-03
Rated Rotation Speed of
Motor1
0~60000 - rpm O O O O X X O
02-04 Rated Voltage of Motor1
230V: 50.0~240.0 220.0
V O O O O X X O
400V: 100.0~480.0 440.0
02-05 Rated Power of Motor1 0.01~600.00 - kW O O O O X X O
02-06 Rated Frequency of Motor1 5.0~599.0 60.0 Hz O O O O X X O
02-07 Poles of Motor 1 2~16(Even) 4 - O O O O X X O
02-08 Reserved
02-09
Excitation Current of Motor
1
15%~70% of Motor Rated Current - % X X O O X X X
02-10
Core Saturation Coefficient
1 of Motor 1
1~100 - % X X O O X X X
02-11
Core Saturation Coefficient
2 Motor 1
1~100 - % X X O O X X X
02-12
Core Saturation Coefficient
3 of Motor 1
80~300 - % X X O O X X X
02-13 Core loss of Motor 1 0.0~15.0 - % O O X X X X O
02-14 Reserved
02-15
Resistance between Wires
of Motor 1
0.001~60.000 - Ω O O O O X X O
02-16
02-17
02-18
Reserved
02-19 No-Load Voltage of Motor 1
230V: 50~240 -
V X X O O X X X
400V: 100~480 -
02-20 No-Load Current of Motor 2 0.01~600.00 - A O X X X X X X
02-21 Rated Current of Motor 2 10%~200% of inverter’s rated current - A O X X X X X X
02-22
Rated Rotation Speed of
Motor 2
0~60000 - rpm O X X X X X X
02-23 Rated Voltage of Motor 2
230V: 50.0~240.0 220.0
V O X X X X X X
400V: 100.0~480.0 440.0
02-24 Rated Power of Motor 2 0.01~600.00 - kW O X X X X X X
02-25 Rated Frequency of Motor 2 5.0~599.0 60.0 Hz O X X X X X X
02-26 Poles of Motor 2 2~16 (Even) 4 - O X X X X X X
02-27
~
02-31
Reserved
02-32
Resistance between Wires
of Motor 2
0.001~60.000 - Ω O X X X X X X
02-33
Proportion of Motor Leak-
age Inductance
0.1~15.0
S % X X O O X X X
02-34 Motor Slip Frequency 0.10~20.00
1.78 Hz X X O O X X X
02-35
~
02-36
Reserved
02-37 Motor Mechanical Loss 0.0~10.0 4.0 % X X X O O X X
60 VDI100 • Instruction manual
