gefran VDI100 Series User Manual

Group 03: External Digital Input and Output Parameters
Code Parameter Name Setting Range Default Unit
Control mode
Attribute
V/f
V/f
+PG
SLV SV
PM
SV
PM
SLV
SLV2
03-00
Multi-Function
Terminal
Function Setting-S1
0: 2-Wire Sequence (ON: Forward Run
Command).
0 -
O O O O O O O
1: 2-Wire Sequence (ON: Reverse Run
Command).
O O O O O O O
2: Multi-Speed/Position Setting Command 1 O O O O O O O
3: Multi-Speed/Position Setting Command 2 O O O O O O O
4: Multi-Speed/Position Setting Command 3 O O O O O O O
5: Multi-Speed/Position Setting Command 4 O O O O O O O
6: Forward Jog Run Command O O O O O O O
03-01
Multi-Function
Terminal
Function Setting-S2
7: Reverse Jog Run Command
1 -
O O O O O O O
8: UP Frequency Increasing Command O O O O O O O
9: DOWN Frequency Decreasing Command O O O O O O O
10: Acceleration/Deceleration Time Selection 1 O O O O O O O
11: Inhibit Acceleration/ Deceleration Com-
mand
O O O O O O O
12: Main/ Alternative Run Switch Function O O O O O O O
13: Main/ Alternative Frequency Switch
Function
O O O O O O O
03-02
Multi-Function
Terminal
Function Setting-S3
14: Emergency Stop (decelerate to zero and
stop)
2 -
O O O O O O O
15: External Baseblock Command (rotation
freely to stop)
O O O O O O O
16: PID Control Disable O O O O O O O
17: Fault Reset (RESET) O O O O O O O
18: Reserved - - - - - - -
19: Speed Search 1 (from the maximum
frequency)
O O O O O X O
20: Manual Energy Saving Function O O X X X X X
03-03
Multi-Function
Terminal
Function Setting-S4
21: PID Integral Reset
3 -
O O O O O O O
22~23 : Reserved - - - - - - -
24: PLC Input O O O O O O O
25: External Fault O O O O O O O
26: 3-Wire Sequence (Forward/Reverse
command).
O O O O O O O
27: Local/ Remote Selection O O O O O O O
03-04
Multi-Function
Terminal
Function Setting-S5
28: Remote Mode Selection
4
O O O O O O O
29: Jog Frequency Selection O O O O O O O
30: Acceleration/ Deceleration Time Selection 2 O O O O O O O
31: Inverter Overheating Warning O O O O O O O
32: Sync Command O O O O O O O
33: DC Braking O O O O X X O
34: Speed Search 2 (from the frequency
command)
O O O O O X O
35: Timing Function Input O O O O O O O
36: PID Soft Start Disable O O O O O O O
03-05
Multi-Function
Terminal
Function Setting-S6
37: Traversing Operation
17 -
O O X X X X O
38: Upper Deviation of Traverse Operation O O X X X X O
39: Lower Deviation of Traverse Operation O O X X X X O
40: Switching between Motor 1/Motor 2 O O X X X X O
41: PID Sleep - - - - - - -
42: PG Disable X O X X X X X
43: PG Integral Reset
X O X O O X X
03-06
Multi-Function
Terminal
Function Setting-S7
44: Mode Switching between Speed and
Torque
29*
(26)*
-
X X X O O X X
45: Negative Torque Command X X X O O X X
46: Zero-Servo Command X X X O O X X
47: Fire mode(Forced Operation mode) O O O O O O O
48: KEB Acceleration O O X X X X O
49: Parameters Writing Allowable O O O O O O O
50: Unattended Start Protection (USP) O O O O O O O
VDI100 • Instruction manual 61
