Group 03: External Digital Input and Output Parameters
Code Parameter Name Setting Range Default Unit
Control mode
Attribute
V/f
V/f
+PG
SLV SV
PM
SV
PM
SLV
SLV2
03-07
Multi-Function
Terminal
Function Setting-S8
51: Mode Switching between Speed and
Position
15 -
X X X O O X X
52: Multi Position Reference Enable X X X O O X X
53: 2-Wire Self Holding Mode (Stop Com-
mand)
O O O O O O O
54: Reserved - - - - - - -
55: Reserved - - - - - - -
56: Reserved - - - - - - -
57: Reserved - - - - - - -
58: Digital Input Stop Command O O O O O O O
59: Reserved - - - - - - -
60: Reserved - - - - - - -
61: Reserved - - - - - - -
62: EPS Function O O O O O O O
63: Reserved - - - - - - -
64: Reserved - - - - - - -
65: Short-circuit braking X X X X X O X
03-08 (S1~S8) DI Scan Time
0: Scan Time 4ms
1 - O O O O O O O
1: Scan Time 8ms
03-09
Multi-Function Terminal S1-
S4 Type Selection
xxx0b: S1 A Contact
xxx1b: S1 B Contact
0000b - O O O O O O O
xx0xb: S2 A Contact
xx1xb: S2 B Contact
x0xxb: S3 A Contact
x1xxb: S3 B Contact
0xxxb: S4 A Contact
1xxxb: S4 B Contact
03-10
Multi-Function Terminal S5-
S8 Type Selection
xxx0b: S5 A Contact
xxx1b: S5 B Contact
0000b - O O O O O O O
xx0xb: S6 A Contact
xx1xb: S6 B Contact
x0xxb: S7 A Contact
x1xxb: S7 B Contact
0xxxb: S8 A Contact
1xxxb: S8 B Contact
03-11 Relay (R1A-R1C) Output 0: During Running 0 - O O O O O O O
1: Fault Contact Output O O O O O O O
2: Frequency Agree O O O O O O O
3: Setting Frequency Agree O O O O O O O
4: Frequency Detection 1 (> 03-13+03-14) O O O O O O O
5: Frequency Detection 2 (< 03-13+03-14) O O O O O O O
6: Automatic Restart O O O O O O O
7: Reserved - - - - - - -
8: Reserved - - - - - - -
9: Baseblock O O O O O O O
10: Reserved - - - - - - -
11: Reserved - - - - - - -
12: Over-Torque Detection O O O O O O O
13: Current Agree O O O O O O O
14: Mechanical Braking Control (03-17~18) O O O O O O O
15: Reserved - - - - - - -
16: Reserved - - - - - - -
17: Reserved - - - - - - -
18: PLC status O O O O O O O
19: PLC Control Contact O O O O O O O
03-12 Relay (R2A-R2C) Output 20: Zero Speed 1 - O O O O O O O
21: Inverter Ready O O O O O O O
22: Under Voltage Detection O O O O O O O
23: Source of Operation Command O O O O O O
O
24: Source of Frequency Command O O O O O O O
25: Low Torque Detection O O O O O O O
26: Frequency Reference Missing O O O O O O O
27: Timing Function Output O O O O O O O
28: Traverse Operation UP Status O O X X X X O
62 VDI100 • Instruction manual
