gefran VDI100 Series

Group 04: External Analog Input and Output Parameters
Code Parameter Name Setting Range Default Unit
Control mode
Attribute
V/f
V/f
+PG
SLV SV
PM
SV
PM
SLV
SLV2
14: Positive / Negative Torque Limit X X O O O O X
15: Torque Reference/ Torque Limit (in
Speed Control)
X X X O O X X
16: Torque Compensation X X O O O X X
17: PTC Overheat Protection O O O O O O O
04-06
AI2 Signal Scanning and
Filtering Time
0.00~2.00 0.03 s O O O O O O O
04-07 AI2 Gain 0.0~1000.0 100.0 % O O O O O O O *1
04-08 AI2 Bias -100.0~100.0 0 % O O O O O O O *1
04-09
~
04-10
Reserved
04-11 AO1 Function Setting 0: Output Frequency 0 - O O O O O O O
1: Frequency Command O O O O O O O
2: Output Voltage O O O O O O O
3: DC Voltage O O O O O O O
4: Output Current O O O O O O O
5: Output Power O O O O O O O
6: Motor Speed O O O O O O O
7: Output Power Factor O O O O O O O
8: AI1 Input O O O O O O O
9: AI2 Input O O O O O O O
10: Torque Command X X O O O O X
11: q-axis Current X X O O O O X
12: d-axis Current X X O O O O X
13: Speed Deviation X X X O O X X
14: Reserved - - - - - - -
15: ASR Output X O X O O X X
16: Reserved - - - - - - -
17: q-axis Voltage X X O O O O X
18: d-axis Voltage X X O O O O X
19: Reserved - - - - - - -
20: Reserved - - - - - - -
21: PID Input O O O O O O O
22: PID Output O O O O O O O
23: PID Target Value O O O O O O O
24: PID Feedback Value O O O O O O O
25: Output Frequency of the Soft Starter O O O O O O O
26: PG Feedback X O X O O X X
27: Reserved - - - - - - -
28: Communication control O O O O O O O
04-12 AO1 Gain 0.0~1000.0 100.0 % O O O O O O O *1
04-13 AO1 Bias -100.0~100.0 0 % O O O O O O O *1
04-14 Reserved
04-15 Reserved
04-16 AO2 Function Setting
Range and definition are the same as
those of 04-11.
3 - O O O O O O O
04-17 AO2 Gain 0.0~1000.0 100.0 % O O O O O O O *1
04-18 AO2 Bias -100.0~100.0 0 % O O O O O - *1
04-19
AO2 Output Signal Type
0: AO2 0~10V
0 - O O O O O O O
1: AO2 4~20mA
04-20
Filter Time of AO Signal
Scan
0.00~0.50 0.00 s O O O O O O O *1
VDI100 • Instruction manual 65
