gefran VDI100 Series

Group 05: Multi-Speed Parameters
Code Parameter Name Setting Range Default Unit
Control mode
Attribute
V/f
V/f
+PG
SLV SV
PM
SV
PM
SLV
SLV2
05-30
Deceleration Time Setting
of Multi Speed 6
0.1~6000.0 10.0 s O O O O O O O
05-31
Acceleration Time Setting
of Multi Speed 7
0.1~6000.0 10.0 s O O O O O O O
05-32
Deceleration Time Setting
of Multi Speed 7
0.1~6000.0 10.0 s O O O O O O O
05-33
Acceleration Time Setting
of Multi Speed 8
0.1~6000.0 10.0 s O O O O O O O
05-34
Deceleration Time Setting
of Multi Speed 8
0.1~6000.0 10.0 s O O O O O O O
05-35
Acceleration Time Setting
of Multi Speed 9
0.1~6000.0 10.0 s O O O O O O O
05-36
Deceleration Time Setting
of Multi Speed 9
0.1~6000.0 10.0 s O O O O O O O
05-37
Acceleration Time Setting
of Multi Speed 10
0.1~6000.0 10.0 s O O O O O O O
05-38
Deceleration Time Setting
of Multi Speed 10
0.1~6000.0 10.0 s O O O O O O O
05-39
Acceleration Time Setting
of Multi Speed 11
0.1~6000.0 10.0 s O O O O O O O
05-40
Deceleration Time Setting
of Multi Speed 11
0.1~6000.0 10.0 s O O O O O O O
05-41
Acceleration Time Setting
of Multi Speed 12
0.1~6000.0 10.0 s O O O O O O O
05-42
Deceleration Time Setting
of Multi Speed 12
0.1~6000.0 10.0 s O O O O O O O
05-43
Acceleration Time Setting
of Multi Speed 13
0.1~6000.0 10.0 s O O O O O O O
05-44
Deceleration Time Setting
of Multi Speed 13
0.1~6000.0 10.0 s O O O O O O O
05-45
Acceleration Time Setting
of Multi Speed 14
0.1~6000.0 10.0 s O O O O O O O
05-46
Deceleration Time Setting
of Multi Speed 14
0.1~6000.0 10.0 s O O O O O O O
05-47
Acceleration Time Setting
of Multi Speed 15
0.1~6000.0 10.0 s O O O O O O O
05-48
Deceleration Time Setting
of Multi Speed 15
0.1~6000.0 10.0 s O O O O O O O
* If the maximum output frequency of motor is over 300HZ, the frequency resolution is changed to 0.1Hz
Group 06: Automatic Program Operation Parameters
Code Parameter Name Setting Range Default Unit
Control mode
Attribute
V/f
V/f
+PG
SLV SV
PM
SV
PM
SLV
SLV2
06-00
Auto Run (sequencer) mode
selection
0: Disabled 0 - O O O X X X O
1: Execute a single cycle operation mode.
Restart speed is based on the previous
stopped speed.
2: Execute continuous cycle operation.
Restart speed is based on the previous
stopped speed.
3: After the completion of a single cycle,
the on-going operation speed is based on
the speed of the last stage. Restart speed
is based on the previous stopped speed.
4: Execute a single cycle operation.
Restart speed is based on the Speed-Sta-
ge 0.
VDI100 • Instruction manual 67
