gefran VDI100 Series

Group 06: Automatic Program Operation Parameters
Code Parameter Name Setting Range Default Unit
Control mode
Attribute
V/f
V/f
+PG
SLV SV
PM
SV
PM
SLV
SLV2
5: Execute continuous cycle operation.
Restart speed is based on the Speed-Sta-
ge 0.
6: After completion of a single cycle, the
on-going operation speed is based on the
speed of the last stage. Restart speed is
based on the Speed-Stage 0
06-01
*Frequency Setting of
Operation-Stage 1
0.00~599.00 5.00 Hz O O O X X X O *1
06-02
*Frequency Setting of
Operation-Stage 2
0.00~599.00 10.00 Hz O O O X X X O *1
06-03
*Frequency Setting of
Operation-Stage 3
0.00~599.00 20.00 Hz O O O X X X O *1
06-04
*Frequency Setting of
Operation-Stage 4
0.00~599.00 30.00 Hz O O O X X X O *1
06-05
*Frequency Setting of
Operation-Stage 5
0.00~599.00 40.00 Hz O O O X X X O *1
06-06
*Frequency Setting of
Operation-Stage 6
0.00~599.00 50.00 Hz O O O X X X O *1
06-07
*Frequency Setting of
Operation-Stage 7
0.00~599.00 50.00 Hz O O O X X X O *1
06-08
*Frequency Setting of
Operation-Stage 8
0.00~599.00 5.00 Hz O O O X X X O *1
06-09
*Frequency Setting of
Operation-Stage 9
0.00~599.00 5.00 Hz O O O X X X O *1
06-10
*Frequency Setting of
Operation-Stage 10
0.00~599.00 5.00 Hz O O O X X X O *1
06-11
*Frequency Setting of
Operation-Stage 11
0.00~599.00 5.00 Hz O O O X X X O *1
06-12
*Frequency Setting of
Operation-Stage 12
0.00~599.00 5.00 Hz O O O X X X O *1
06-13
*Frequency Setting of
Operation-Stage 13
0.00~599.00 5.00 Hz O O O X X X O *1
06-14
*Frequency Setting of
Operation-Stage 14
0.00~599.00 5.00 Hz O O O X X X O *1
06-15
*Frequency Setting of
Operation-Stage 15
0.00~599.00 5.00 Hz O O O X X X O *1
06-16
Operation Time Setting of
Speed-Stage 0
0.0~6000.0 0.0 s O O O X X X O *1
06-17
Operation Time Setting of
Speed-Stage 1
0.0~6000.0 0.0 s O O O X X X O *1
06-18
Operation Time Setting of
Speed-Stage 2
0.0~6000.0 0.0 s O O O X X X O *1
06-19
Operation Time Setting of
Speed-Stage 3
0.0~6000.0 0.0 s O O O X X X O *1
06-20
Operation Time Setting of
Speed-Stage 4
0.0~6000.0 0.0 s O O O X X X O *1
06-21
Operation Time Setting of
Speed-Stage 5
0.0~6000.0 0.0 s O O O X X X O *1
06-22
Operation Time Setting of
Speed-Stage 6
0.0~6000.0 0.0 s O O O X X X O *1
06-23
Operation Time Setting of
Speed-Stage 7
0.0~6000.0 0.0 s O O O X X X O *1
06-24
Operation Time Setting of
Speed-Stage 8
0.0~6000.0 0.0 s O O O X X X O *1
06-25
Operation Time Setting of
Speed-Stage 9
0.0~6000.0 0.0 s O O O X X X O *1
06-26
Operation Time Setting of
Speed-Stage 10
0.0~6000.0 0.0 s O O O X X X O *1
06-27
Operation Time Setting of
Speed-Stage 11
0.0~6000.0 0.0 s O O O X
X X O *1
68 VDI100 • Instruction manual
