gefran VDI100 Series

Group 06: Automatic Program Operation Parameters
Code Parameter Name Setting Range Default Unit
Control mode
Attribute
V/f
V/f
+PG
SLV SV
PM
SV
PM
SLV
SLV2
06-47
Operation Direction Se-
lection of Speed-Stage 15
0: Stop
0 - O O O X X X O1: Forward
2: Reverse
* If the maximum output frequency of motor is over 300HZ,the frequency resolution is changed to 0.1Hz
Group 07: Start /Stop Parameters
Code Parameter Name Setting Range Default Unit
Control mode
Attribute
V/f
V/f
+PG
SLV SV
PM
SV
PM
SLV
SLV2
07-00
Momentary Power Loss/
Fault Restart Selection
0: Disable
0 - O O O O X X O
1: Enable
07-01 Fault Auto-Restart Time 0~7200 0 s O O O O O O O
07-02
Number of Fault Auto-Re-
start Attempts
0~10 0 - O O O O O O O
07-03 Reserved
07-04 Direct Start at Power on
0: When the external run command is
enabled, direct start at power up
1 - O O O O O O O
1: When the external run command is
enabled, unable to direct start at power-
up.
07-05
Delay of Direct Start at
Power on
1.0~300.0 3.5 s O O O O O O O
07-06
DC Injection Braking Star-
ting Frequency
0.0~10.0 0.5 Hz O O O O
O O O
07-07 DC Injection Braking Current 0~100 50 % O O O
X X X O
07-08
DC Injection Braking Time
at Stop
0.00~100.00 0.50 s O O O O
O X O
07-09 Stop Mode Selection 0: Deceleration to Stop 0 - O O O O X X O
1: Coast to Stop
2: DC Braking Stop in All Fields
3: Coast to Stop with Timer
07-10
~
07-12
Reserved
07-13
Low Voltage Detection
Level
230V: 150~300 190
V O O O O O O O
400V: 250~600 380
07-14 Pre-excitation Time 0.00~10.00 2.00 s X X O X X X X
07-15 Pre-excitation Level 50~200 100 % X X O X X X X
07-16
DC Injection Braking Time
at Start
0.00~100.00 0.00 s O O O O
O X O
07-17 Reserved
07-18 Minimum Base block Time 0.1~5.0 - s O O O O X O O
07-19
Direction-Detection Speed
Search Operating Current
0~100 50 % O X O X X X O
07-20
Speed Search Operating
Current
0~100 20 % O X O X X X O
07-21
Integral Time of Speed
Searching
0.1~10.0 2.0 s O X O X X X O
07-22
Delay Time of Speed
Searching
0.0~20.0 0.2 s O O O O O X O
07-23 Voltage Recovery Time 0.1~5.0 2.0 s O O O X X X O
07-24
Direction-Detection Speed
Search Selection
0: Disable
1 - O O O X X X O
1: Enable
07-25 Low Voltage Detection Time 0.00~1.00 0.02 s O O O O O O O
07-26
Start-up Mode Selection of
SLV Coast to Stop
0: Start with speed search
0 - X X O X X X X
1: Normal start
07-27
Start Selection after Fault
during SLV Mode
0: Start with speed search
0 - X X O X X X X
1: Normal start
07-28
Start after External Base
Block
0: Start with speed search
0 - O X O X X X O
1: Normal start
70 VDI100 • Instruction manual
