gefran VDI100 Series

Group 07: Start /Stop Parameters
Code Parameter Name Setting Range Default Unit
Control mode
Attribute
V/f
V/f
+PG
SLV SV
PM
SV
PM
SLV
SLV2
07-29
Run Command Selection at
the Action of DC Braking
0: Not Allowable to Run
0 - O O X X X X X
1: Allowable to Run
07-30 Low Voltage Level Selection
0: Disable
0 -
O O O O O X O
1: Enable
07-31
**Low Voltage Run Fre-
quency
0.00~599.00 10.00 Hz
O O O O O X O
07-32
Speed Search Mode
Selection
0: Disable
0 - O O O O X X X
1: Execute a Speed Search at Power On
07-33
Start Frequency of Speed
Search Selection
0: Maximum Output Frequency of Motor
0 - O O O O X X X
1: Frequency Command
07-34
Start short-circuit braking
time
0.00~100.00 0.00 s X X X X X O X
07-35
Stop Short-circuit braking
time
0.00~100.00 0.50 s X X X X X O X
07-36
Short-circuit braking current
limited
0.0~200.0 100.0 % X X X X X O X
*07-13 Low Voltage Detection Level, it is enable when 07-30 Low Voltage Level Selection set 0 (Enable) and lower frequency limit set to 250V.This application is for Emergency
power supply (EPS)
* *If the maximum output frequency of motor is over 300HZ,the frequency resolution is changed to 0.1Hz
Group 08: Protection Parameters
Code Parameter Name Setting Range Default Unit
Control mode
Attribute
V/f
V/f
+PG
SLV SV
PM
SV
PM
SLV
SLV2
08-00 Stall Prevention Function
xxx0b: Stall prevention is enabled in
acceleration.
0000b - O O O O O O O
xxx1b: Stall prevention is disabled in
acceleration.
xx0xb: Stall prevention is enabled in
deceleration.
xx1xb: Stall prevention is disabled in
deceleration.
x0xxb: Stall prevention is enabled in
operation
x1xxb: Stall prevention is disabled in
operation
0xxxb: Stall prevention in operation is
based on deceleration time of speed-sta-
ge 1.
1xxxb: Stall prevention in operation is
based on deceleration time of speed-sta-
ge 2.
08-01
Stall Prevention Level in
Acceleration
20~200
HD:150
% O O O X X O O
ND:120
08-02
Stall Prevention Level in
Deceleration
230V: 330V~410V 385V
V O O O O X O O
400V: 660V~820V 770V
08-03
Stall Prevention Level in
Operation
30~200
HD:160
% O O X X X X O
ND:120
08-04 Reserved
08-05
Selection for Motor Overlo-
ad Protection (OL1)
xxx0b: Overload Protection is disabled. 0001b - O O O O O O O
xxx1b: Overload Protection is enabled.
xx0xb: Cold Start of Motor Overload
xx1xb: Hot Start of Motor Overload
x0xxb: Standard Motor
x1xxb: Inverter Duty Motor
0xxxb: Reserved
1xxxb: Reserved
VDI100 • Instruction manual 71
