gefran VDI100 Series

Group 08: Protection Parameters
Code Parameter Name Setting Range Default Unit
Control mode
Attribute
V/f
V/f
+PG
SLV SV
PM
SV
PM
SLV
SLV2
08-06
Start-up Mode of Overload
Protection Operation (OL1)
0: Stop Output after Overload Protection
0 - O O O O O O O
1: Continuous Operation after Overload
Protection.
08-07 Reserved
08-08
Automatic Voltage Regula-
tion (AVR)
0: Enable
0 - O O O O O O O
1: Disable
08-09
Selection of Input Phase
Loss Protection
0: Enable
0 - O O O O O O O
1: Disable
08-10
Selection of Output Phase
Loss Protection
0: Enable
0 - O O O O O O O
1: Disable
08-11
~
08-12
Reserved
08-13
Selection of Over-Torque
Detection
0: Over-Torque Detection is Disabled. 0 - O O O O O O O
1: Start to Detect when Reaching the Set
Frequency.
2: Start to Detect when the Operation is
Begun.
08-14
Selection of Over-Torque
Operation
0: Deceleration to Stop when Over Torque
is Detected.
0 - O O O O O O O
1: Display Warning when Over Torque is
Detected. Go on Operation.
2: Coast to Stop when Over Torque is
Detected
08-15
Level of Over-Torque
Detection
0~300 150 % O O O O O O O
08-16
Time of Over-Torque
Detection
0.0~10.0 0.1 s O O O O O O O
08-17
Selection of Low-Torque
Detection
0: Low-Torque Detection is Disabled. 0 - O O O O O O O
1: Start to Detect when Reaching the Set
Frequency.
2: Start to Detect when the Operation is
Begun.
08-18
Selection of Low-Torque
Operation
0: Deceleration to Stop when Low Torque
is Detected.
0 - O O O O O O O
1: Display Warning when Low Torque is
Detected. Go on Operation.
2: Coast to Stop when Low Torque is
Detected
08-19
Level of Low-Torque
Detection
0~300 30 % O O O O O O O
08-20
Time of Low-Torque
Detection
0.0~10.0 0.1 s O O O O O O O
08-21
Limit of Stall Prevention in
Acc over Base Speed
1~100 50 % O O O X X O O
08-22
Stall Prevention Detection
Time in Operation
2~100 100 ms O O O X X O O
08-23 Ground Fault (GF) Selection
0: Disable
0 - O O O O O O O
1: Enable
08-24
External Fault Operation
Selection
0: Deceleration to Stop 0 - O O O O O O O
1: Coast to Stop
2: Continuous Operation
08-25
Detection Selection of
External Fault
0: Immediately Detect when the Power is
Supplied.
0 - O O O O O O O
1: Start to Detect when the Operation is
Started.
72 VDI100 • Instruction manual
