Group 08: Protection Parameters
Code Parameter Name Setting Range Default Unit
Control mode
Attribute
V/f
V/f
+PG
SLV SV
PM
SV
PM
SLV
SLV2
08-26
~
08-29
Reserved
08-30
Digital Input Stop Command
Selection
0: Deceleration to Stop
0 - O O O O O O O
1: Coast to Stop
08-31
08-32
08-33
08-34
Reserved
08-35
Motor Overheat Fault
Selection
0: Disable 0 - O O O O O O O
1: Deceleration to Stop
2: Free Run to top
3: Continue Running
08-36
PTC Input Filter Time
Constant
0.00 ~ 10.00
2 s O O O O O O O
08-37 Fan Control Function 0: Start in operation 0 O O O O O O O
1: Permanent Start
2: Start in high temperature (except of the
models of
6750 or the above)
08-38 Delay Time of Fan Off 0~600 60 s O O O O O O O
08-39
Delay Time of Motor
Overheat Protection
1~300 60 sec O O O O O O O
08-40
Motor2 Acceleration Stall
Prevention Level
20~200
HD:150
% O O O X X O O
ND:120
08-41
Motor2 Acceleration Stall
Prevention Limit
1~100 50 % O O O X X O O
08-42 PTC Protection Level 0~10.0V 0.3 V O O O O O O O
08-43 PTC Restart Level 0~10.0V 1.2 V O O O O O O O
08-44 PTC Warning Level 0~10.0V 0.6 V O O O O O O O
Group 09: Communication Parameters
Code Parameter Name Setting Range Default Unit
Control mode
Attribute
V/f
V/f
+PG
SLV SV
PM
SV
PM
SLV
SLV2
09-00
INV Communication Station
Address
1~31 1 - O O O O O O O
*3
09-01
Communication Mode
Selection
0: MODBUS 0 O O O O O O O
*3
*5
1: Reserved
2: Reserved
3: Reserved
4: PROFIBUS*
09-02 Baud Rate Setting (bps) 0: 1200 4 - O O O O O O O *2
1: 2400
2: 4800
3: 9600
4: 19200
5: 38400
09-03 Stop Bit Selection 0: 1 Stop Bit 0 - O O O O O O O *2
1: 2 Stop Bit
09-04 Parity Selection 0: No Parity 0 - O O O O O O O *2
1: Even Bit
2: Odd Bit
09-05
Communication Data Bit
Selection
0: 8 Bit Data 0 - O O O O O O O *3
1: 7 Bit Data
