gefran VDI100 Series User Manual

Group 12: Monitoring Parameters
Code Parameter Name Setting Range Default Unit
Control mode
Attribute
V/f
V/f
+PG
SLV SV
PM
SV
PM
SLV
SLV2
12-42 RS-485 Error Code
00 00 00 0 0
1: CRC Error
1: Data length Error
1: Data Function Error
1: Parity Error
1: Overrun Error
1: Framing Error
1: Time out Error
Reserved
- - O O O O O O O
12-43 Inverter Status
00 00 00 0 0
1: Inverter ready
1: During running
1: During zero speed
1: During speed agree
1: During fault detection (minor fault)
1: During fault detection (major fault)
Reserved
- - O O O O O O O
12-44 Pulse Input Frequency Display the frequency value of pulse input - Hz O O O O O O O
12-45 Recent Fault Message Display current fault message - - O O O O O O O
12-46 Previous Fault Message Display previous fault message - - O O O O O O O
12-47
Previous Two Fault Mes-
sages
Display previous two fault messages - - O O O O O O O
12-48
Previous Three Fault
Messages
Display previous three fault messages - - O O O O O O O
12-49
Previous Four Fault Mes-
sages
Display previous four fault messages - - O O O O O O O
12-50 DIO Status of Current Fault
Display the DI/DO status of current fault
Description is similar to 12-05
- - O O O O O O O
12-51
Inverter Status of Current
Fault
Display the inverter status of current fault
Description is similar to 12-43
- - O O O O O O O
12-52 Trip Time 1 of Current Fault Display the operation time of current fault,
12-53 is the days, while 12-52 is the
remaining hours.
- Hr O O O O O O O
12-53 Trip Time 2 of Current Fault - day O O O O O O O
12-54
Frequency Command of
Previous Fault
Display frequency command of previous
fault
- Hz O O O O O O O
12-55
Output Frequency of Pre-
vious Fault
Display output frequency of previous fault - Hz O O O O O O O
12-56
Output Current of Previous
Fault
Display output current of previous fault - A O O O O O O O
12-57
Output Voltage of Previous
Fault
Display output voltage of previous fault - V O O O O O O O
12-58 DC Voltage of Previous Fault Display DC voltage of previous fault - V O O O O O O O
12-59 DIO Status of Previous Fault
Display DI/DO status of previous fault
Description is similar to 12-05
- - O O O O O O O
12-60
Inverter Status of Previous
Fault
Display inverter status of previous fault
Description is similar to 12-43
- - O O O O O O O
12-61 Trip Time 1 of Last Fault Display the operation time of last time’s
fault, 12-62 is the days, while 12-61 is the
remaining hours .
- Hr O O O O O O O
12-62 Trip Time 2 of Last Fault - day O O O O O O O
12-63 Recent Warning Messages Display the recent warning messages - - O O O O O O O
12-64 Previous Warning Message Display the previous warning message - - O O O O O O O
12-65 Motor Start Angle 0~360 - - X X X X O X X
12-66 Encoder Angle 0~360 - - X O X O O X X
12-67 Cumulative Energy (kWHr) 0.0 ~ 999.9 kWHr O O O O O O O
12-68 Cumulative Energy (MWHr) 0 ~ 60000 MWHr O O O O O O O
12-69
~
12-75
Reserved
12-76 No-Load Voltage Output 0.0~600.0 - V X X O X X X X
12-77 Reserved
VDI100 • Instruction manual 81
