gefran VDI100 Series User Manual

Group 12: Monitoring Parameters
Code Parameter Name Setting Range Default Unit
Control mode
Attribute
V/f
V/f
+PG
SLV SV
PM
SV
PM
SLV
SLV2
12-78 Z-Phase Bias Value -9999~9999 - Pulse X X X O O X X
12-79 Pulse Input Percentage 0.0~100.0 - % O O O O O O O
*: Refer to the following attachment 1
** VDI100 230V Class 37 kW (50HP), and the above, 400V Class 75 kW (100HP) and the above, don’t support heatsink temperature display function.
Group 13: Maintenance Parameters
Code Parameter Name Setting Range Default Unit
Control mode
Attribute
V/f
V/f
+PG
SLV SV
PM
SV
PM
SLV
SLV2
13-00 Inverter
model Selection ---- - - O O O O O O O *4
13-01 Software Version 0.00-9.99 - - O O O O O O O *4
13-02
Clear Cumulative Operation
Hours
0: Disable to Clear Cumulative Operation
Hours
0 - O O O O O O O *1
1: Clear Cumulative Operation Hours
13-03
Cumulative Operation
Hours 1
0~23 - hr O O O O O O O *4
13-04
Cumulative Operation
Hours 2
0~65535 - day O O O O O O O *4
13-05
Selection of Cumulative
Operation Time
0: Cumulative time in power on 0 - O O O O O O O *1
1: Cumulative time in operation
13-06 Parameters Locked
0: Parameters are read-only except 13-06
and main frequency
2 - O O O O O O O *1
1 : User defined parameters
2: All Parameters are Writable
13-07
Parameter Lock key Code 00000~65535 0 - O O O O O O O
13-08 Restore Factory Setting 0 : No initialization - - O O O O O O O
2 : 2 wire initialization (60Hz) (220/440V)
3 : 3 wire initialization (60Hz) (240/440V)
4 : 2 wire initialization (50Hz) (230/415V)
5 : 3 wire initialization (50Hz) (230/415V)
6 : 2 wire initialization (50Hz) (200/380V)
7 : 3 wire initialization (50HZ) (200/380V)
8 : PLC initialization
9: 2 wire Initialization (60Hz)
(230/460V)
10: 3 wire Initialization (60Hz) (230/460V)
11: 2 wire Initialization (60Hz)(230/400V)
12: 3 wire Initialization (60Hz)(230/400V)
13: 2 wire Initialization (50Hz)(230/400V)
14: 3 wire Initialization (50Hz)(230/400V)
Others: Reserved
13-09
Fault History Clearance
Function
0: No Clearing Fault History 0 - O O O O O O O *1
1: Clear Fault History
13-10
Parameter Password
Function 2
0 ~ 9999 0 O O O O O O O
13-11 C/B CPLD Ver. 0.00~9.99 0.00 O O O O O O O
13-12 PG Card Id 0~255 0 O O O O O O O *5
13-13 PG Card Ver. 0.00~9.99 0.00 O O O O O O O *5
13-14 Fault Storage Selections
0: Fault Messages of Auto Restart are not
saved.
0 O O O O O O O
1: Fault Messages of Auto Restart are
saved.
13-15
Reserved
13-21 Last time Fault History Exhibit Last time Fault History - - O O O O O O O
82 VDI100 • Instruction manual
