gefran VDI100 Series User Manual

Group 15: PLC Monitoring Parameters
Code Parameter Name Setting Range Default Unit
Control mode
Attribute
V/f
V/f
+PG
SLV SV
PM
SV
PM
SLV
SLV2
15-07 T4 Current Value 2 (Mode7) 0~9999 0 - O O O O O O O
15-08 T5 Current Value 1 0~9999 0 - O O O O O O O
15-09 T5 Current Value 2 (Mode7) 0~9999 0 - O O O O O O O
15-10 T6 Current Value 1 0~9999 0 - O O O O O O O
15-11 T6 Current Value 2 (Mode7) 0~9999 0 - O O O O O O O
15-12 T7 Current Value 1 0~9999 0 - O O O O O O O
15-13 T7 Current Value 2 (Mode7) 0~9999 0 - O O O O O O O
15-14 T8 Current Value 1 0~9999 0 - O O O O O O O
15-15 T8 Current Value 2 (Mode7) 0~9999 0 - O O O O O O O
15-16 C1 Current Value 0~65535 0 - O O O O O O O
15-17 C2 Current Value 0~65535 0 - O O O O O O O
15-18 C3 Current Value 0~65535 0 - O O O O O O O
15-19 C4 Current Value 0~65535 0 - O O O O O O O
15-20 C5 Current Value 0~65535 0 - O O O O O O O
15-21 C6 Current Value 0~65535 0 - O O O O O O O
15-22 C7 Current Value 0~65535 0 - O O O O O O O
15-23 C8 Current Value 0~65535 0 - O O O O O O O
15-24 AS1 Current Value 0~65535 0 - O O O O O O O
15-25 AS2 Current Value 0~65535 0 - O O O O O O O
15-26 AS3 Current Value 0~65535 0 - O O O O O O O
15-27 AS4 Current Value 0~65535 0 - O O O O O O O
15-28 MD1 Current Value 0~65535 0 - O O O O O O O
15-29 MD2 Current Value 0~65535 0 - O O O O O O O
15-30 MD3 Current Value 0~65535 0 - O O O O O O O
15-31 MD4 Current Value 0~65535 0 - O O O O O O O
15-32 TD Current Value 0~65535 0 - O O O O O O O
Group 16: LCD Function Parameters
Code Parameter Name Setting Range Default Unit
Control mode
Attribute
V/f
V/f
+PG
SLV SV
PM
SV
PM
SLV
SLV2
16-00 Main Screen Monitoring
5~79
when using LCD to operate, the monitored
item displays in the first line. (default is
frequency command)
16 - O O O O O O O *1
16-01 Sub-Screen Monitoring 1
5~79
when using LCD to operate, the monitored
item displays in the second line. (default
is output frequency)
17 - O O O O O O O *1
16-02 Sub-Screen Monitoring 2
5~79
when using LCD to operate, the monitored
item displays in the third line. (default is
output current)
18 - O O O O O O O *1
16-03 Display Unit
0~39999
Determine the display way and unit of
frequency command
0 - O O O O O O O
0: Frequency display unit is 0.01Hz
1: Frequency display unit is 0.01%
2: Frequency display unit is rpm.
3~39: Reserved
40~9999:
Users specify the format, Input 0XXXX
represents the display of XXXX at 100%.
10001~19999:
Users specify the format; Input 1XXXX
represents the display of XXX.X at 100%.
VDI100 • Instruction manual 85
