6 Front/Rear Panel
cally sets the sequencer for Song Style recording. Holding the button
pressed for a few seconds gains access to the Clear function which al-
lows you to cancel recording errors and parts not wanted (all, chord, etc.)
PLAY/STOP starts and stops the Song Style recording and playback and
the playback of Songs.
28. UTILITY. 6 useful functions which affect the instrument in several
different ways. METRONOME activates/deactivates the metronome in play-
back and record mode. SUSTAIN applies the sustain effect to the three
keyboard sections (Upper 1, 2 and Lower). HARMONY enables/disables
the melody harmony function according to the current Harmony Type.
VOCAL P: gains access to the Vocal Processor functions. Reverb acti-
vates/deactivates the Reverb effect processor. CHORUS activates/deacti-
vates the Chorus effect processor (delay/modulations). Holding down
the VOCAL P, HARMONY, REVERB and CHORUS buttons gains access to the
edit of the corresponding function.
29. SAMPLING (RECORD, SAMPLES). RECORD ACTIVATES THE SAMPLING
PROCESS
, ALLOWING YOU RECORD YOUR VOICE (THROUGH A MICROPhone) or a
musical instrument connected to the Mic/Line jack of the Vocal Proces-
sor interface. SAMPLES gains access to the SAMPLES bank (disk-based
Samples can be loaded to the Sample bank even if the Vocal Processor
is not installed).
30. PITCH/MODULATION BALL. This physical controller is preset for
PITCH BEND (horizontal movements) and MODULATION (vertical movements)
which affect the Performance tracks enabled for one or both effects.
31. HEADPHONES. Jacks for headphones connection (optional). Con-
necting a pair of stereo headphones to the left jack automatically exclude
the internal speakers (for silent playing). connecting to the right jack
does not affect the internal speaker system.
32. DISK DRIVE. The Disk Drive is situated to the left of the instrument,
under the keyboard. This device works with 3.5" DD disks and 2HD
disks.
