- 101 -
Measure the free length of the valve spring.
Allowable limit: Spring: 37 mm
Measure the outer diameter of the valve stem.
Allowable limit: Intake Ф4.455 mm
Exhaust Ф4.448 mm
Check valve guide. Please eliminate the carbon
deposition in the valve guide with a reamer before
inspection.
Attention: Rotate the reamer in clockwise. Please do
not rotate the reamer in counterclockwise.
Valve reamer
Vernier
cali
