- 87 -
Engine Inspection and Maintenance
Table of tightening torque for fastening parts used in engine
Table of tightening torque for fastening parts
Names of fastening parts and fasteners Fastening torque (N·m)
Cylinder head cover screw M6 10-14
Cam cover fastening screw M5 7
Cylinder head cover screw M6 12
Cylinder head cover acorn nut M8 25-28
Cylinder stud bolt M8 25-28
Tensioner fastening screw M6 10
Chains leading fastening screw M8 8
Oil pipe set bolt M8 10
Thermostat fastening screw M6 7
Induction manifold fastening bolt M6 7
Flywheel locking hexnut M12 55
Starting engine set bolt M6 8
Clutch transmission gear jam nut M16 70
Clutch jam nut M16 70
Gearshift star-wheel fastening screw M6 8
Gearshift positioning wheel rocker arm fastening screw M6 8
Mould assembling screw M6 10
Left and right crankcase cap bolt M6 10
Cylinder head cover fastening screw M6 8
Water pump cover fastening screw M6 8
Machine oil strainer cover M6 8
Engine cover fastening screw M6 7
Machine oil strainer plug screw M20 25
Oil pump cover fastening screw M6 8
Coil fastening screw M6 8
Output sprocket nut M18 72
Spark plug M10 10-15
Water temperature sensor M12 16
Magnetic bolts M12 15
