- 48 -
3.3.2.3 Front Bearing Inspection
Disassemble front wheel central lining and take down oil seal.
Check the rolling condition of bearing.
If not rolling, or the bearing is worn or loose, replace with a new one.
3.3.3 Bearing Replacement
Disassemble front wheel 、 front axle and axle sleeve and then
disassemble oil seal with oil seal stripping attachment and bearing with
bearing stripping attachment.
Note: Removed bearing shall be replaced with a new bearing.
Apply some lubricating grease on the bearing at installation.
And then press the bearing in with bearing installer.
* Attention
• The bearing must be pushed in parallel.
• Bearing oil seal sleeve must be pressed
in from the out.
3.3.4 Installation
Oil seal on front wheel should be spread with lubricating grease.
Autometer gearing mesh and moving parts should be spread with lubricating grease.
Fold odometer wheel gear units and then install brake disc
Front wheel
intermediate
bushing
Grease seal
