- 68 -
5.8 disassembly of alternator
5.8.1 Disassembly
Disassemble fixed b
olt and bolt
T
ake down left cover
Fix flywheel with
universal fixed wr
ench
Disassemble flyw
heel fixed nut
T
ake down flywheel with flywheel puller
Disassemble solid key
Disassemble alternator guide li
ne joint
Disassemble alternator stator
固定
螺母
Fixed
Nut
螺栓
Bolt
72
74
