Generic TR 125 Service Manual

- 85 -
8.6 Instrument
Remove rear mirror.
Take down the handle hood and pull out waterproof connector.
Remove the bolts.
Remove meter housing
Remove the instrument.
Install the instrument orderly in the reverse order of removal.
8.7 Main Switch
8.7.1 Inspection
Disassemble front guard board
Disassemble master switch guide line joint
Break over test of joint side
8.7.2 Master switch replacement
Disassemble body front guard board
Disassemble fixed bolt and take down master switch fixed seat
Disassemble fixed bolt and replace master switch.
