- 78 -
VII Starting System
Preparatory data-------- 7.1
Fault diagnosis----------7.2
Starting motor-----------7.3
Starting relay------------7.4
7.1 Preparatory Data
Precautions on operation
Starting motor removal can be performed on the engine.
Starting clutch removal refers to removal instruction.
Basic data
Item Standard Service Limit
Length of starting carbon brush 12.5mm 8.5mm
Starting idler shaft bushing 8.3mm
Starting idler shaft OD 7.94mm
Tightening torque
Starting motor clutch cap bolt 12 N·m
Starting motor clutch locknut 95 N·m
Tools
Locknut wrench
Universal un-adjustable wrench
