Generic TR 125 - Service Plan; Scheduled Maintenance and Warranty Service

- 45 -
III Front Wheel/Front Suspension
Preparatory data-----------------3.1
Fault diagnosis------------------3.2
Front wheel----------------------3.3
Control assembly---------------3.4
Front fork assembly------------3.5
3.1 Preparatory Data
Precautions on operation
Before removing the front wheel, lift and support the bottom of motorcycle with a jack or other available
device. The front wheel is off the ground. Take care not to rotate the wheel reversely.
Attention: Please do not let oil contaminate braking shoe.
Basic data of the motorcycle as a whole
Measuring position Item Standard value(mm) Service Limit(mm)
Front wheel shaft Curvature 0.2
Front wheel Wheel shimmy
Longitudinal 2.0
Transversal Within 1.0 2.0
Tightening torque
Tools
Direction handle fixed screw 22-29 N·m Bearing disassembly pole
Front axle 37-44 N·m
3.2 Fault diagnosis
3.2.1 Direction handle moves hard
z Direction handle is out of order or damaged
z Bearing failure of direction handle
z Faucet bearing rating nut is too tight
z Tire pressure is not enough
