Generic TR 125 - Alternator Charging Coil; Alternator Light Coil

- 67 -
Multimeter
+
-
White1
Red/white
Red Black White2
Unit: MΩ
White1 No No 0.1~3 10~90
red/white
No No 0.1~3 No
Red 0.1~3 No 1.2~5 0.1~3
Black No No No No
White2 60~80 No No 0.1~3
5.6 Alternator Charging Coil
* Attention
Inspection of alternator charging coil can
be performed on the engine.
Inspection
Disassemble alternator 4P joint
Measure Alternator white coil and impedance between bodies with multimeter
Standard value: 0.6-1Ω（20）
If measured value exceeds the standard, the alternator coiling shall be replaced.
5.7 alternator light coil
* Attention
Inspection of alternator charging coil can
be performed on the engine.
Inspection
Measure Alternator white coil and impedance between body bondings with multimeter
Standard value: 0.6-1Ω（20）
If measured value exceeds the standard, the alternator coiling shall be replaced.
