- 84 -
8.4 Front Turn Signal Lamp Bulb Replacement
8.4.1 Removal
Loosen turn signal lamp fixed bolt
Take down bulb from bulb socket
8.4.2 Installation
Install bulb back in the verse order of disassemble.
8.5 Taillight/license plate lamp/rear turn-lamp bulb replacement
8.5.1 Disassembly
Disassemble bolt and taillight shade.
Disassemble bulb from socket
8.5.2 Installment
Install bulb back in the verse order of disassemble.
8.5.3 Rear turn signal lamp replacement
8.5.3.1 Disassembly
Disassemble bolt and taillight shade.
Disassemble bulb from socket
8.5.3.2 Installment
Install bulb back in the verse order of disassemble.
Left and
right turn
signal lamps
Head
lamp
