Generic TR 125 Service Manual

- 7 -
Specifications (QJ125GY-16A)
Model
QJ125GY-16A
Engine
Engine type
QJ160MI-A
Overall Length (mm)
2030 Fuel type
92# or 95# unleaded
gasoline
Overall Width (mm)
845 Number of cylinders 1
Overall height (mm)
1120 Bore*stroke Ф60 mm *44 mm
Wheelbase (mm)
1385 Displacement 124.4
Vehicle Weight (kg)
Front
axle
63kg Starting mode Electric
Rear
axle
76kg Cooling mode Water cooled
Total
139kg Lubricating mode
Force-feed and splash
lubrication
Wheel Specification
Front (External)
Fuel tank capacity 1.2L(Oil change1L)
100/80-17
Rear（External）
Air cleaner Filter sponge
130/80-17
Drive Train
Clutch type
Wet multi-plate
friction type
Fuel tank capacity 7.5L ± 0.2L
Performance
Top speed 110 km/h
Gear shift pattern Manual 6 gear
Slope climbing force
Maximum climbing angle
is not less than 20 degrees
Idle speed 1700± 100rpm/min
Drive Train Clutch type
Max. torque 12.18N·m/7500r/min
Electrical
Battery
capacity/type
12V-6AH/YUASA
TT27SL
Max. power 11 Kw/ 9000 r/min
Generator type
Alternating current
permanent magnetic
motor
Compression ratio 12.0 : 1
Spark plug NGK CR8E Pressure of cylinder 8.5Mpa
Spark plug
clearance
0.7~0.8mm
Braking
system
Diameter of front
brake disc
φ280mm
Ignition type CDI
Diameter of rear
brake disc
φ240mm
